CS-C8PF (2.8mm+12mm)

Key Features

EZVIZ products have been designed for your entertainment, communication and security. When you install the EZVIZ APP on your smartphone or tablet, EZVIZ devices will be connected to the cloud via their QR code and will immediately be online. With EZVIZ , you can watch your child’s progress when you are away, keep an eye on your home, interact with your four-legged friends and prevent household accidents.

Intelligent Dual Lenses
AI Human shape detection
360°visual coverage
8X mix Zoom
Weatherproof Design
Black & White night vision (Up to 98ft/30m)
IR Night Vision (Up to 98 ft / 30 m)
Picture-in-Picture Display Mode

Datasheet: CS-C8PF (2.8mm+12mm)

Camera

Image sensor: Dual-1/2.7″ Progressive Scan CMOS
Shutter Speed: Self-adaptive shutter
Lens: 2.8mm @F1.6+12mm @F1.6
PT Angle: Pan: 340, Tilt: 80°
Minimum Illumination: 0.05Lux @(F1.6 AGC ON), 0 Lux with IR
Lens Mount: M12
Day & Night: IR-cut filter with auto switch
DNR: 3D DNR
WDR: Digital WDR
BLC: Supports
Night Vision: 30m/98ft

Video & Audio

Max. Resolution: 1920 × 1080
Frame Rate: Max:15fps; Self-Adaptive during network transmission
Video Compression: H.265 / H.264
H.265 Type: Main Profile
Video Bit Rate: Ultra-HD; HD; Standard. Adaptive bit rate.
Audio Bit Rate: Self-Adaptive
Max. Bitrate: 2Mbps

Function

Smart Alarm: AI Human Detection
Customized Alert Area: Supports
Audio: Supports mic
General Function: Anti-Flicker, Dual-Stream, Heart Beat, Password Protection,
Watermark

Storage

Local Storage: Micro SD card slot (Max. 512G)
Cloud Storage: EZVIZ Cloud Storage

General

Operating Conditions: -30ºC ~ 60ºC ( 14°F to 113 °F ), Humidity 95% or less ( non-
condensing)
IP Grade: Weatherproof Design
Power Supply: DC 12V/1A
Power Consumption: MAX. 12W
Dimensions: 154 × 116 × 164 mm (6.06 × 4.57 × 6.46 inch)
Packaging Dimensions: 197 × 185 × 205 mm (7.76 × 7.28 × 8.07 inch)
Weight
- Product: 578 g (20.39 oz)
- With package: 938g (33.07 oz)

We deliver High quality CCTV Cameras to cater all your needs. Within our cheap and high end models This Ezviz CS-C8PF (2.8mm+12mm) specifically have the integration of a 12 mm telephoto lens and a 2.8 mm wide-angle lens.
