Model Parameters
Camera
Image Sensor 1/2.7″ Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 2.8mm @ F1.6, view angle: 105° (Horizontal), 120°(Diagonal)

4 mm @ F1.6, view angle: 89° (Horizontal), 106° (Diagonal)

Min. Illumination color night vision, 0.005 lux
Lens Mount M8
DNR 3D DNR
WDR Digital WDR
Compression
Video Compression H.264 / H.265
Video Bit Rate Full HD; HD; Standard. Adaptive bit rate.
Max. Resolution 1920 × 1080
Frame Rate 50Hz: 25fps; Self-Adaptive during network transmission
BLC Supports
Interface
Storage MicroSD card slot (Max. 256 GB)
Wired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Network
Smart Alarm Motion detection, human shape detection, vehicle shape detection
Setup Motion Detection Area Supports
Wi-Fi Pairing AP paring
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Wi-Fi
Standard IEEE802.11b/g/n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Transmission Rate 11b: 11 Mbps, 11g: 54 Mbps, 11n: 144 Mbps
General
Power Supply DC 12V±10%
Power Consumption Max. 12W
IR Range Max. 30 meters (98.43 feet)
IP Grade IP67
Dimensions 72 x 72 x 150 mm (2.83 x 2.83 x 5.9 inch)
Packaging Dimensions 253.5 x 111.5 x 93.5 mm (9.98 x 4.39 x 3.68 inch)
Weight 425g (0.94 lb)
Package Contents
Package Contents C3X Camera; Drill Template; Screw Kit; Waterproof Kit; Power Adapter 1.5 m (4.9 ft.); Quick Start Guide
Operating Environment
Temperature -30°C to 60°C (-22°F to 140°F )
Humidity 95% or less (non-condensing)
Certificates
Certificates UL / FCC / CE / WEEE / REACH / RoHS
