Datasheet: C3W Pro
User Manual: C3W Pro
| Model Parameters | |
|---|---|
| Camera | |
| Image Sensor | 1/2.7”Progressive Scan CMOS |
| Minimum Illumination | 0.01 lux @(F1.6, AGC ON), 0 lux with IR |
| Shutter Speed | Self-adaptive shutter |
| Lens | 2.8 mm @F1.6, view angle: 103° horizontal, 119° diagonal 4 mm @F1.6, view angle: 87° horizontal, 104° diagonal |
| Lens Mount | M12 |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Compression | |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Full HD; HD; Standard. Adaptive bit rate. |
| General | |
| Working Temperature | -30 °C to 60 °C (22 °F to 140 °F) |
| Working Humidity | 95% or less (non-condensing) |
| Power Supply | DC 12 V / 1 A |
| Power Consumption | Max. 6 W |
| IP Grade | IP67 |
| Night Vision Distance (Black/White Night Vision Mode) | Max. 30 m (98.43 ft.) |
| Dimensions | 72 mm × 72 mm × 150 mm (2.83” × 2.83” × 5.91”) |
| Packaging Dimensions | 252 mm × 110 mm × 92 mm (9.92” × 4.33” × 3.62”) |
| Net Weight | 352 g(0.78 lbs) |
| Network | |
| User Defined Alarm Tones | Supports |
| Wi-Fi Pairing | AP Pairing |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Max. Bitrate | 2M |
| Wi-Fi | |
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 144 Mbps |
| Image | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | Max: 30 fps; Self-adaptive during network transmission |
| Interface | |
| Storage | MicroSD card slot (Max. 256 GB) |
| Wired Network | RJ45 × 1(10 M / 100 M Adaptive Ethernet Port) |
| In the box | |
| In the box | C3W Pro (4MP) Color Night Vision Camera ; Power Adapter (1.5 m) ; Mounting Template ; Screw Kit ; Waterproof Kit ; Quick Start Guide |
| Certifications: | |
| Certifications: | UL / FCC / CE / WEEE / REACH / RoHS |
The Ezviz C3W Pro, with color night vision camera, is embedded with an AI algorithm to provide the person detection and precise alerts. Call our hotline to find details and Invest in smart security features and its accessories.
