| Model |
CS-TY2 (2MP) |
| Model Parameters |
| Camera |
| Image Sensor |
F2.4@1/3″ Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4mm@ F2.4, view angle: 85° diagonal, 75° horizontal, 45° vertical |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto-switching |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| Compression |
| Video Compression |
H.264 |
| Video Bit Rate |
Adaptive bit rate. |
| Image |
| Max. Resolution |
1920 × 1080 |
| Frame Rate |
Max:15fps; Self-Adaptive during network transmission |
| Network |
| Smart Alarm |
Motion detection |
| Wi-Fi Pairing |
AP pairing |
| Protocol |
EZVIZ Cloud proprietary protocol |
| Interface Protocol |
EZVIZ Cloud proprietary protocol |
| Interface |
| Storage |
MicroSD card slot (Max. 256GB) |
| Power |
Micro USB |
| Wired Network |
RJ45 X 1 (10M/100M self-adaptive Ethernet port) |
| Wi-Fi |
| Standard |
IEEE802.11b/g/n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
Supports 20MHz |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate |
11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps |
| Operating Environment |
| Temperature |
-10°C to 45°C (14°F to 113 °F) |
| Humidity |
95% or less (non-condensing) |
| General |
| Power Supply |
DC 5V/1A |
| Power Consumption |
5W max |
| IR Range |
MAX. 10 meters (32.81 ft.) |
| Dimensions |
88 x 88 x 124 mm (3.46 x 3.46 x 4.88 inch) |
| Packaging Dimensions |
103 x 103 x 186 mm (4.06 x 4.06 x 7.32 inch) |
| Net Weight |
255 g (8.99 oz) |
| In the box: |
| In the box: |
TY2 Pan/Tilt Camera; Base; Screw Kit; Power Cable 3m (9.8 ft.); Drill Template ; Power Adapter ; Quick Start Guide |
| certificates： |
| certificates： |
FCC / UL / CE / WEEE / REACH / RoHS |
