CS-C2C (1080P,H.265)/CS-C2C-A0-1E2WF Description Ezviz Smart Home Camera ezvizlanka Srilanka
Datasheet: CS-C2C (1080P,H.265)


User Manual: CS-C2C (1080P,H.265)

Model

CS-C2C (1080P,H.265)

Camera

Image Sensor 1/3″ Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 2.8 mm, view angle: 108° (Diagonal), 91° (Horizontal), 50° (Vertical)
Minimum Illumination 0.5 Lux @(F2.2, AGC ON), 0 Lux with IR
Lens Mount M12
Day & Night IR-cut filter with auto-switching
DNR 3D DNR
Night Vision 10 m

Video & Audio

Max. Resolution 1920 × 1080
Frame Rate Max:25 fps; Self-Adaptive during network transmission
Video Compression H.265 / H.264
H.265 Type Main Profile
Video Bit Rate HD; Standard. Adaptive bit rate.
Audio Bit Rate Self-adaptive
Max. Bitrate 1 Mbps

Function

Smart Alarm Motion detection
Two-way Talk Supports
General Function Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark

Network

Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Transmission Rate 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol

Storage

Local Storage MicroSD card (max. 256 GB)
Cloud Storage EZVIZ Cloud Storage

General

Operating Conditions -10 ºC ~ 45 ºC (14 °F ~ 113 °F ), Humidity 95% or less ( non-condensing)
Power Supply DC 5V / 1A
Power Consumption Max. 4.0 W
Product Dimensions 110 × 58 × 38 mm (4.33 x 2.28 x 1.50 inch)
Packaging Dimensions 149 × 91.5 × 87.5 mm (5.87 x 3.60 x 3.44 inch)
Net Weight 100 g (3.53 oz)
Weight (With Package) 292 g (10.30 oz)

In the box:

In the box: – C2C Camera – USB Cable – 3-Meter Power Adapter – Foam Sticker – Metal Plate – Base – Drill Template – Screw Kit – Regulatory Information – Quick Start Guide

Certifications:

Certifications: FCC/UL/CE/RoHS/WEEE/REACH
