Datasheet: CS-C1C-D0-1D1WFR
User Manual: CS-C1C-D0-1D1WFR
Model | CS-C1C-D0-1D1WFR | |
---|---|---|
Model Parameters | ||
Camera | ||
Image Sensor | 1/4″ Progressive Scan CMOS | |
Shutter Speed | Self-adaptive shutter | |
Lens | 2.8mm, view angle:92° (Horizontal), 110°(Diagonal) | |
Lens Mount | M12 | |
Day & Night | IR-cut filter with auto-switching | |
DNR | 3D DNR | |
Image | ||
Max. Resolution | 1280 x 720 | |
Frame Rate | Max. 25fps; Self-adaptive during network transmission | |
Compression | ||
Video Compression | H.264 | |
H.264 Type | Main profile | |
Video Bit Rate | HD; Standard; Basic. Adaptive bit rate | |
Auto Bit Rate | Self-adaptive | |
Max. Bitrate | 2Mbps | |
Network | ||
Smart Alarm | Motion detection | |
Wi-Fi Pairing | AP pairing | |
Protocol | EZVIZ cloud proprietary protocol | |
Interface Protocol | EZVIZ cloud proprietary protocol | |
General Features | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark | |
Interface | ||
Storage | Support Micro SD card (Max. 256G) | |
Power | Micro USB | |
Wi-Fi | ||
Standard | IEEE802.11b, 802.11g, 802.11n | |
Frequency Range | 2.4 GHz ~ 2.4835 GHz | |
Channel Bandwidth | Supports 20MHz | |
Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK | |
Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps | |
General | ||
Requirements | – 10 – 45°C (14 – 113°F) Humidity 95% or less (non-condensing) | |
Power Supply | DC 5V±10% | |
Power Consumption | Max. 4.0W | |
IR Range | Max. 12 meters | |
Product Dimensions | 64mm x 64mm x 103mm | |
Packaging Dimensions | 123mm x 79mm x 125.5mm | |
Weight | 96g |
