Datasheet: CB2 4G
User Manual: CB2 4G
| Camera | |
|---|---|
| Image Sensor | 1/2.8″ 3-Megapixel Progressive Scan CMOS Sensor |
| Minimum Illumination | 0.01 Lux |
| Shutter Speed | Self-adaptive shutter |
| Lens | 4 mm @ F1.6
Field of view: 106° (diagonal), 90° (horizontal), 48°(vertical) |
| Lens Mount | M12 |
| Day & Night | IR-cut Filter with Auto Switch |
| DNR | 3D DNR |
| Night Vision | Up to 8 m / 26 ft |
| Video & Audio | |
| Max. Resolution | 2304 × 1296 |
| Frame Rate | 15 fps. Self-Adaptive during network transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Ultra-HD; Full HD; Hi-Def
Adaptive bit rate |
| Audio Bit Rate | Self-Adaptive |
| Max. Bitrate | 1.5 Mbps |
| Network | |
| Frequency Bands | EU LTE-FDD：B1 / B3 / B5 / B7 / B8 / B20 / B28
LA LTE-FDD：B2 / B3 / B4 / B5 / B7 / B8 / B28 / B66 |
| Function | |
| Smart Alarm | Supports |
| Customized Alert Area | Supports |
| Two-way Talk | Supports |
| Storage | |
| Local Storage | Supports microSD card (max. 512 GB) |
| Cloud Storage | Supports EZVIZ CloudPlay storage (subscription required) |
| General | |
| Operating Conditions | -10°C to 45°C (14°F to 113 °F )
Humidity 95% or less (non-condensing) |
| Power Supply | DC 5 V / 2 A (purchased separately) |
| Battery Capacity | 2000 mAh |
| Dimensions | 52 × 39.1 × 39.1 mm (2.47 ×1.54 × 1.54 inch) |
| Packaging Dimensions | 126 × 91× 50 mm (4.96 × 3.58 × 1.97 inch) |
| Weight | Bare Weight: 90 g (3.17 oz)
With Package: 303 g (10.68 oz) |
| In the box | |
| In the box | – Camera |
| – Magnetic Base | |
| – Power Cable | |
| – Foam Sticker × 2 | |
| – Metal Plate (5 mm Hole Diameter) | |
| – Screw Kit | |
| – Regulatory Information × 2 | |
| – Quick Start Guide | |
| Certifications | |
| Certifications | CE / REACH / WEEE / RoHS |
